Description | Specification |
Dimensions(WxLxH) | 20'x30'x12' |
Door size (WxH) (Front & Rear) | 14'x10.5' |
Door Type | Zipper Rollup Door |
Frame | Single Truss Galvanized Tube |
Steel Frame | Hot Dip Galvanized Steel |
Truss tube | 16 Gauge |
Tarp Fabric | PE or PVC |
Tarp Color (customizable) | White with Green/Red Edge |
Temperature resistance | -22 - +158 °F |
Arch Φ | Φ 70x42x1.5mm |
Purlin Φ | Φ 40x1.2mm |
Arch Spacing | 6 ft |
Number of Arch | 6 |
Number of Anchor plates | 12 |
Tension System | Pipe and Ratchet Tie-Down System |
Average assembly time for DIY with 4 persons | 1 Day |
Snow Load | 42 lbs/ft² |
Wind Load | 50 miles/h |
Tarp lifespan | 7-10 years, depending on the type of fabric and environmental conditions. |
Frame lifespan | 15+ Years |
Warranty | - PE: 2 Years Warranty. - PVC: 8 Years Warranty. |
Fabric (Optional) |
|
